Antenna Pattern
|
In the Americas | |
Sales | |
+1 (201) 342-3338 phone | |
+1 (201)-342-3339 fax | |
89 Leuning Street | |
South Hackensack, NJ 07606 | |
USA | |
Customer Service | |
+1 (201) 342-3338 phone | |
+1 (201)-342-3339 fax | |
89 Leuning Street | |
South Hackensack, NJ 07606 | |
USA | |
Technical Support | |
+1 (201) 342-3338 phone | |
+1 (201)-342-3339 fax | |
89 Leuning Street | |
South Hackensack, NJ 07606 | |
USA | |
|
||||
Ultra Wideband Six-Beam Special Events Antenna | MBA6-9F-E-H3 | |||
|
The CCI Six-Beam Special Events Antenna is an LTE ready multi-beam antenna that supports multiple sectors (6) from a single antenna. This Six-Beam Antenna is intended for use at sporting and entertainment venues where social media and the ability to share photos and videos demand high capacity and high data rates. This Six-beam antenna has one row of six dual +45° and -45° cross-polarized beam pairs, each roughly 15 degrees apart that are used to segment large audiences into multiple sectors. The antenna enables maximum spectrum re-use by sectorization, providing as much as nine times increase in network capacity. Our unique beam shaping technology provides fast roll off between beams, minimizing interference between sectors thus increasing the carrier to interference plus noise ratio (CINR) and lowering soft handover losses in LTE networks. Such an approach enhances data transfer rates within LTE network sectors and addresses “hotspots” in mobile wireless operator networks. CCI antennas are designed and produced to ISO 9001 certification standards for reliability and quality in our state-of-the-art manufacturing facilities. |
Ports | 12 × High Band Ports which cover the full range from 1695-2690 MHz | ||||
Frequency Range | 1695-1880 MHz | 1850-1990 MHz | 1920-2180 MHz | 2300-2400 MHz | 2496-2690 MHz |
Gain | 20.6 dBi | 21.4 dBi | 21.6 dBi | 22.2 dBi | 22.6 dBi |
Azimuth Beamwidth (-3dB) | 11.0° | 10.0° | 9.3° | 7.8° | 7.1° |
Azimuth Beam Crossover | 10.7 dB | 10.4 dB | 10.4 dB | 10.7 dB | 10.1 dB |
Elevation Beamwidth (-3dB) | 14.0° | 12.8° | 12.1° | 10.6° | 9.6° |
Electrical Downtilt | 6° | 6° | 6° | 6° | 6° |
Elevation Sidelobes (1st Upper) (Typ.) | < -22 dB | < -20 dB | < -19 dB | < -21 dB | < -19 dB |
Front-to-Back Ratio @180° (Tpy.) | > 40 dB | > 40 dB | > 40 dB | > 40 dB | > 40 dB |
Cross-Polar Port-to-Port Isolation | > 30 dB | > 30 dB | > 30 dB | > 30 dB | > 30 dB |
Interbeam Co-Pol Isolation | > 15 dB | > 15 dB | > 15 dB | > 15 dB | > 15 dB |
Interbeam Co-Pol Isolation (Non-Adjacent Beams) (Worse Case) | > 13 dB | > 13 dB | > 15 dB | > 13 dB | > 14 dB |
Voltage Standing Wave Ratio(VSWR) | < 1.5:1 | < 1.5:1 | < 1.5:1 | < 1.5:1 | < 1.5:1 |
Passive Intermodulation (2×20W) | ≤ -153 dBc | ≤ -153 dBc | ≤ -153 dBc | ≤ -153 dBc | ≤ -153 dBc |
Input Power Continuous Wave per Port | 200 watts | 200 watts | 200 watts | 200 watts | 200 watts |
Polarization | Dual Pol 45° | Dual Pol 45° | Dual Pol 45° | Dual Pol 45° | Dual Pol 45° |
Input Impedance | 50 ohms | 50 ohms | 50 ohms | 50 ohms | 50 ohms |
Lightning Protection | DC Ground | DC Ground | DC Ground | DC Ground | DC Ground |
Dimensions (L×W×D) | 27.9×41.7×7.5 in (708×1058×191 mm) |
Survival Wind Speed | > 150 mph (> 241 kph) |
Front Wind Load1 | 214 lbf @ 100 mph 953 N @ 161 kph |
Side Wind Load1 | 13 lbf @ 100 mph 60 N @ 161 kph |
Effective Projective Area (EPA), Front1 | 8.6 ft2 (0.8 m2) |
Weight * | 63.7 lbs (28.9 kg) |
Package Dimensions (LxWxD) | 35.1×51.5×15.0 in (891×1307×380 mm) |
Package Weight | 93.0 lbs (42.2 kg) |
RF Connector | 12 × 7-16 DIN long neck female or 12 × 4.3-10 female |
Mounting Pole | 2 to 5 in (5 to 12 cm) |
1Windload values calculated using CFD analysis * weight excludes mounting kit and is for the heavier MBA6-9F-W-H3-C1 version |
Bottom View | |
Connector Spacing | |
MBA6-9F-E-H3-C1-K | Three foot (0.7 m) Special Events Six-Beam Antenna with Fixed Electrical Tilt and 7-16 DIN Female connectors and MBK-03 mounting bracket |
MBA6-9F-E-H3-C2-K | Three foot (0.7 m) Special Events Six-Beam Antenna with Fixed Electrical Tilt and 4.3-10 Female connectors and MBK-03 mounting bracket |
MBK-03 | Mounting bracket kit (top and bottom) with 0° to 12° mechanical tilt adjustment |
