      Bi-SectorTM Array BSA33R-BW6B




  PI BSA33RBU6B front iso PI BSA33RBU6B rear iso
  • Six foot (1.8 m), multiband, Sixteen port Dual Band Bi-SectorTM Antenna. Deploying two independent high performing pairs of CCI’s Patented Asymmetrical 33° Shaped Beams covering 698-896 MHz and 1695-2180 MHz frequencies
  • Eight wide high band ports covering 1695-2180 MHz and eight wide low band ports covering 698-896 MHz in a single antenna
  • Full Spectrum Compliance for 698-896 MHz /1695-2180 MHz
  • Implementing a new Patented Array Architecture, where gain has been significantly improved, while maintaining superior Co-Pol ISO between beams and superior El SLL performance
  • Provides two independent pairs of LTE Optimized Asymmetric Shaped Beams for improved LTE data throughput by minimizing beam crossover, providing for an efficient use of valuable radio capacity and frequency spectrum
  • LTE Optimized FBR, SPR and Boresight/Sector XPD Performance, essential for today’s LTE Data Networks
  • Exceeds minimum PIM performance requirements
  • Equipped with new 4.3-10 connector, which is 40% smaller than traditional 7/16 DIN connector
  • Equipped with Four Field Replaceable, integrated AISG 2.0 compliant Remote Electrical Tilt (RET)
MBK-01 MBK-01 Mounting Kit with 0° - 10° mechanical tilt
MBK-16 MBK-16 Mounting Kit with fixed 0° mechanical tilt
BSA-RET400 Type 17 Internal Remote Electrical Tilt System (RET)
AISGC-M-F-10FT 10 Foot (3 M) Male/Female AISG cable
SCU-AISG-P Portable AISG 2.0 Site Control Unit
Configuration File
