      DAS Interface Conditioner Module DAST-xxxx-MODx-x




  DASTXXXXMODCS FV MODC
  • Modular Design, Common for all bands
  • A common connection point to the DAS system for multiple BTS’s, platforms and spectrums
  • Level Control for each BTS input allows for independent adjustment of TX & RX power
  • Easy optimization features including separate Uplink and Downlink control
  • Can support both 0 dBm and +30 dBm DAS TX inputs (high and low power)
  • All connections are on front panel for Easy access
  • Sample ports for easy optimization, troubleshooting and maintenance
  • High Rejection Duplexer Filters
  • Designed for ultra low PIM performance
  • Supports MIMO and SIMO Configurations
  • Flexible design and configuration options
  • Optional Duplex output to DAS System available
