Datasheet

Multi-Band Eight Port Antenna

OPA65R-BU4D

Four foot (1.2 m) multiband, eigth port antenna with a 65° azimuth beamwidth covering 698-896 MHz and 1695-2400 MHz frequencies
Four high band ports covering 1695-2400 MHz and four low band ports covering 698-896 MHz in a single antenna enclosure
Full Spectrum Compliance for WCS and AWS-3 frequencies and Band 14 Operations
Array configuration allows for 4T4R (4X4 MIMO) on Low Band, essential for Band 14 Operations
LTE Optimized FBR and SPR performance, providing for an efficient use of valuable radio capacity
LTE Optimized Boresight and Sector XPD and USL performance, essential for LTE Performance
Exceeds minimum PIM performance requirements
Equipped with new 4.3-10 connector, which is 40% smaller than traditional 7/16 DIN connector
Ordering options for External RET Controllers (Type 1) or Internally Integrated RET Controllers (Type 17)

Overview

The CCI Multi-Port multiband array is a eight port antenna, with four wide band ports covering 1695-2400 MHz and four low band ports covering 698-896 MHz. The antenna provides the capability to deploy 4×4 Multiple-input Multiple-output (MIMO) in the high band and 4X4 Multiple-input Multiple-output (MIMO) across low band ports. The CCI 8-Port allows independent tilt control between the low band ports and high band ports. In this two RET configuration, the 1st RET is dedicated for the four Low Band ports and the 2rd RET is for the four High Band ports.

CCI antennas are designed and produced to ISO 9001 certification standards for reliability and quality in our state-of-the-art manufacturing facilities.

Applications

4×4 MIMO for the High Band and 4X4 MIMO Low Band ports
Ready for Network Standardization on 4.3-10 DIN connectors
With CCI’s multiband antennas, wireless providers can connect multiple platforms to a single antenna, reducing tower load, lease expense, deployment time and installation costs

Electrical


Ports	4 × Low Band Ports for 698-896 MHz
Frequency Range	698-806 MHz	824-896 MHz
Gain¹	13.2 dBi	14.0 dBi
Gain (Average)²	12.2 dBi	13.0 dBi
Azimuth Beamwidth (-3dB)	73°	62°
Elevation Beamwidth (-3dB)	20.1°	17.7°
Electrical Downtilt	2° to 16°	2° to 16°
Elevation Sidelobes (1st Upper)	<-16 dB	<-17 dB
Front-to-Back Ratio @180°	> 32 dB	> 32 dB
Front-to-Back Ratio ±20°	> 30 dB	> 30 dB
Cross-Polar Discrimination at Peak	> 25 dB	> 25 dB
Cross-Polar Discrimination at Sector²	14.6 dB	11.4 dB
Cross-Polar Port-to-Port Isolation	> 25 dB	> 25 dB
Voltage Standing Wave Ratio (VSWR)	< 1.5:1	< 1.5:1
Passive Intermodulation (2×20W)	≤ -153 dBc	≤ -153 dBc
Input Power Continuous Wave (CW)	500 watts	500 watts
Polarization	Dual Linear 45°	Dual Linear 45°
Input Impedance	50 ohms	50 ohms
Lightning Protection	DC Ground	DC Ground
¹Peak gain across sub-bands. ²Electrical specifications follow document "Recommendation on Base Station Antenna Standards" (BASTA) V9.6.


Ports	4 × High Band Ports for 1695-2400 MHz
Frequency Range	1695-1880 MHz	1850-1990 MHz	1920-2180 MHz	2300-2400 MHz
Gain¹	16.4 dBi	16.4 dBi	16.7 dBi	17.0 dBi
Gain (Average)²	15.5 dBi	15.9 dBi	16.1 dBi	16.6 dBi
Azimuth Beamwidth (-3dB)	68°	69°	70°	59°
Elevation Beamwidth (-3dB)	8.2°	7.3°	6.7°	5.9°
Electrical Downtilt	2° to 10°	2° to 10°	2° to 10°	2° to 10°
Elevation Sidelobes (1st Upper)	<-16 dB	<-16 dB	<-16 dB	<-16 dB
Front-to-Back Ratio @180°	> 35 dB	> 35 dB	> 35 dB	> 35 dB
Front-to-Back Ratio ±20°	> 30 dB	> 30 dB	> 30 dB	> 30 dB
Cross-Polar Discrimination at Peak	> 18 dB	> 17 dB	> 17 dB	> 18 dB
Cross-Polar Discrimination at Sector²	9.4 dB	7.7 dB	8.1 dB	8.9 dB
Cross-Polar Port-to-Port Isolation	> 25 dB	> 25 dB	> 25 dB	> 25 dB
Voltage Standing Wave Ratio (VSWR)	< 1.5:1	< 1.5:1	< 1.5:1	< 1.5:1
Passive Intermodulation (2×20W)	≤ -153 dBc	≤ -153 dBc	≤ -153 dBc	≤ -153 dBc
Input Power Continuous Wave (CW)	300 watts	300 watts	300 watts	300 watts
Polarization	Dual Linear 45°	Dual Linear 45°	Dual Linear 45°	Dual Linear 45°
Input Impedance	50 ohms	50 ohms	50 ohms	50 ohms
Lightning Protection	DC Ground	DC Ground	DC Ground	DC Ground
¹Peak gain across sub-bands. ²Electrical specifications follow document "Recommendation on Base Station Antenna Standards" (BASTA) V9.6.

Mechanical

Dimensions (L×W×D)	48.0×20.7×7.7 in (1220×525×197 mm)
Survival Wind Speed	> 150 mph (> 241 kph)
Front Wind Load	212 lbs (943 N) @ 100 mph (161 kph)
Side Wind Load	90 lbs (402 N) @ 100 mph (161 kph)
Equivalent Flat Plate Area	8.3 ft² (0.8 m²)
Weight *	46.3 lbs (21.0 kg)
Packaging Dimensions (L×W×D)	60.2×26.9×15.0 in (1530×683×381 mm)
Packaged Weight ~	79.4 lbs (36.0 kg)
Connector	8 × 4.3-10 female
Mounting Pole	2 to 5 in (5 to 12 cm)

* Weight excludes mounting

Bottom View

Connector Spacing

RET to Element Configuration	OPA65R-BU4DA Element and RET configuration (Type 1 External RET)

Typical Antenna Patterns

For detailed information on additional antenna patterns, contact customer support at


	722 MHz Azimuth with Elevation 9°	880 MHz Azimuth with Elevation 9°


	1850 MHz Azimuth with Elevation 6°	2155 MHz Azimuth with Elevation 6°

MBK-02		MBK-02 Mounting Kit
MBK-15		MBK-15 Mounting Kit with fixed 0° mechanical tilt
BSA-RET200		Type 1 External Remote Electrical Tilt System (RET)
BSA-RET400		Type 17 Internal Remote Electrical Tilt System (RET)
CBK-AG-RRU-001		AISG Cable set for two RET antenna with Type 1 RET
CBK-RA-AG-RRU-005		AISG Right Angle Cable set for two RET antenna with Type 1 RET
AISGC-M-F-10FT		10 Foot (3 M) Male/Female AISG cable for Type 17 RET
SCU-AISG-P		Portable AISG 2.0 Site Control Unit

Product Information

	Datasheet
	OPA65R-BU4DA Connector Spacing Diagram
	OPA65R-BU4DA Antenna/RET Config Diagram
	MBK-02 Installation Guide
	MBK-15 Installation Guide

	Interactive Pattern Viewer
	CCI Interactive Pattern Viewer Instructions

Antenna Pattern

OPA65RBU4D: Text/Planet Format - Default Azimuth

Configuration File

	RET Antenna configuration file update procedure

For Firmware select RET Actuator link below.

BSA-RET200 SA-DC0301
Configuration File	Version
OPA65-BU4D-HB01.BIN	01
OPA65-BU4D-HU01.BIN	01

BSA-RET200 SA-DC0401E
Configuration File	Version
OPA65-BU4D-YB02.BIN	02
OPA65-BU4D-YU02.BIN	02

Parts & Accessories

OPA65R-BU4DA-K	Four foot (1.2 m) antenna with 65° azimuth beamwidth, 4.3-10 female connectors, 2 factory installed BSA-RET200 RET actuators (Type 1 external) and MBK-15 mounting bracket
OPA65R-BU4DB-K	Four foot (1.2 m) antenna with 65° azimuth beamwidth, 4.3-10 female connectors, 2 factory installed BSA-RET400 RET actuators (Type 17 internal) and MBK-15 mounting bracket
MBK-02	Mounting bracket kit (top and bottom) with 0° to 10° mechanical tilt adjustment
MBK-15	Mounting Kit with fixed 0° mechanical tilt
BSA-RET200	Type 1 External Remote Electrical Tilt System (RET)
BSA-RET400	Type 17 Internal Remote Electrical Tilt System (RET)
CBK-AG-RRU-001	Antenna with 2 Type 1 RET to RRU AISG cable kit
CBK-RA-AG-RRU-005	Antenna with 2 Type 1 RET to RRU AISG right angle cable kit
AISGC-M-F-xFT AISGC-M-F-10FT	10 Ft (3 m) Male/Female RRU to Antenna AISG cable

Standards & Compliance

Safety	EN 60950-1, UL 60950-1
Emission	EN 55022
Immunity	EN 55024
Environmental	IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-5, IEC 60068-2-6, IEC-60068-2-11, IEC 60068-2-14, IEC 60068-2-18, IEC 60068-2-27, IEC 60068-2-29, IEC 60068-02-30, IEC 60068-2-52, IEC 60068-2-64, GR-63-CORE 4.3.1, EN 60529, IP 24

Certifications

Antenna Interface Standards Group (AISG), Federal Communication Commission (FCC) Part 15 Class B, CE, CSA US, ISO 9001

	Interactive Pattern Viewer
	CCI Interactive Pattern Viewer Instructions
